Quick Totem Capstan 1000W 12V QTM1000G

Quick Totem Capstan 1000W 12V

€1,618.18 VAT included

€1,326.38 VAT excluded

€2,157.57-25%

Shipping from Italy or Europe warehouse in 4-8 working days unless otherwise specified in the product description

Quick Totem Capstan 1000W 12V, The capstan is generally used for mooring and manoeuvring activities (dock line handling). This capstan is in chromed-plated bronze, vertical motor to facilitate installation. High efficiency of the epicyclical gearbox, allowing higher motor performance.
For boats from 11 to 14 metres.

Technical features:
- Motor power: 1000W;
- Motor supply voltage12V;
- Maximum pull: 820 kg;
- Maximum working load: 290 kg;
- Working load: 95 kg;
- Current absorbtion @ working load (1): 80A;
- Maximum chain speed (2):  25,8 m/min;
- Maximum chain speed @ working load (2): 16,8 m/min;
- Drum diameter: 80 mm;
- Weight: 8,1 kg.

Solenoid included.

Quick
QTM1000G
8025223008413
